Home > MOT Equipment > Brake Testers > R100 Class 2 Motorcycle Brake Tester

Brake Testers

R100 Class 2 Motorcycle Brake Tester

Approved for MoT testing, the boston range of brake testers are without question the latest and most up-to-date equipment available. They enable fast and accurate brake testing for motorcycles. The R100 boasts a host of features including LED matrix displays allowing both analogue and digital display of readings, automatic calculation of brake efficiency, infra-red remote control operation, dual-directional operation, ovality testing, printer facility with full company details (optional), weighing scales (optional), wallor pedestal mounting, and above all - peace of mind that you have the latest technology in your workshop with a qualified technical service team to back it up.

  • Power: 220 V / 400 V / 50Hz / 16 A
  • Motor: Dual Directional – 1.5 kW
  • Electronics: Microprocessor Controlled
  • Brake Testing Speed: 2.9 km/h
  • Weighing System: 4 Point
  • Max. Brake Force (per wheel): 300 kgf
  • Max. Wheel Load: 750 kg
  • Roller Bed Weight and Build: 80 kg – Fully Galvanised
  • Rolled Bed Chassis Dimensions: 80 x 62 x 31 cm (L x W x H)
  • Display Dimensions: 67 x 50 x 12 cm (L x W x H)
  • Roller Width: 300 mm
  • Roller Centre Dimension: 400 mm
  • Friction Roller Surface: 0.9 µdry, > 0.6 wet
  • Communication: Full RS232/Bluetooth
  • Operator Control:Remote infra-red
